It used in different industries: heavy vehicles, mining machinery, forestry machinery, construction, agricultural, et

Our team is committed to full-process

tracking and transparent delivery to ensure that there are no mistakes in every

link.

Continuously costom our products （ladder width/extension rack/load/color, etc）based on customer feedback to meet the needs of different customers.

Tare Weight:10500kg

Load Weight:60000kg

Dimensions  Overall Dimensions:13000x3000x1200 mm

(Loading deck 9400*3000*1200mm)

Beam Main beam:Q355B

Main Beam Height:500mm

Upper Plate:18mm

Lower Plate:20mm

Web Plate:12mm

Platform :5mm

Axle:3*13Ton

Suspension:Leaf spring

Tyre:12R22.5 (275/70r222.5 optional)

Kin Pin:50

Brake Chamber:Six double chambers

Relay Valve:WABCO relay valve

Lamps:A full set of LED lights

Voltage:24V

Receptacle:7 ways

Tool Box:Included

Spare Wheel Carrier:One

Hook:Included

Lader:Mechnical lader 80cm

Painting :Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
