Tare Weight:8600kg

Load Weight:60000kg

Dimensions (LxWxH)Overall Dimensions:12500x2500x3000 mm

(Dropside height 80cm,front board 150cm)

Main Beam Material:Q355B steel

Main Beam Height:500mm

Upper Plate:14mm

Lower Plate:16mm

Web Plate:8 mm

Platform:4mm

Axle:4*13Ton axle

Suspension:Leaf spring suspension with first axle lifted(optional)

Tyre:12R22.5 tire 16+1

King Pin:Bolt 2.0inch

Landing Gear:28Ton

Brake Chamber:Eight double chambers

Lamps:A full set of LED lights

Voltage:24V

Receptacle:7 ways

Tool Box:one

Spare Wheel Carrier:One

Twist Lock:12 pcs

Front board Include

Hook:Included

Color:Green,white,yellow etc

Painting:Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
