Tare Weight :4000KG

Load Weight :30000KG

Dimensions (LxWxH)Overall Dimensions:7000x2500x1480 mm

Main Beam Material:T700 High strength steel

Main Beam Height:500mm

Upper Plate:10mm

Lower Plate:12mm

Web Plate:6mm

Axle:2*13Ton axle

Suspension:Leaf spring suspension

Tyre:12R22.5 9pcs（include one spare）

Rim:9pcs

Landing Gear:28Ton  landing gear

King Pin:Bolt  2.0inch

Brake Chamber:Four double chambers

Lamps:A full set of LED lights

Voltage:24V

Receptacle:7 ways

Tool Box:Equipped one set with basic tools

Spare Wheel Carrier:One

Twist Lock:4

Spare tire:One

Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
