Tare Weight :9800kg

Load Weight :40000kg

Dimensions (LxWxH)Overall Dimensions:11500x2500x3800 mm

Tank shap & capacity :square round shape .42000liters+3% ,3 compartments with fuel guage.

Tank material: Tank body Q235 5mm，Tank end plate:Q235 6mm, Baffle:Q235 5mm

Chassis:Q355 steel ＋Heavy duty and extra durability designed.

 Manhole Cover: 3 units of 500mm aluminium manhole cover,Euro standard

Valve: 3 sets discharge valve, 3sets bottom valve

 Discharge hose:2pcs 6m

Others:Anti skid walking way for the whole tank and side guard.Anti-static tape+Fire extinguisher

Axle:3*13Ton axle

Suspension:Leaf spring suspension

Tyre:12R22.5 12+1pcs

King Pin:Bolt 2.0inch

Landing Gear:28tons

Brake Chamber:Six double chambers

Relay Valve:WABCO relay valve

ABS:include

Lamps:A full set of LED lights

Voltage:24V

Receptacle:7 ways

Tool Box:one

Spare wheel rack:two

Spare tire:one

Painting :1 coat of anticorrosive prime, 2 coats of final paint.100um wax spray

Shipping term Bulk ship or roro ship
