Tare Weight:11000kg

Load Weight:60000kg

Dimensions (LxWxH)Overall Dimensions:9500x2550x3800 mm

(Dump box 9000x2350x1600) 34M3

Main Beam Material:Q355B steel

Main Beam Height:500mm

Upper Plate:14mm

Lower Plate:16mm

Web Plate:8 mm

Dump box:Side 4mm,end 6mm

Axle:3*13Ton axle

Suspension :Strength Leaf spring suspension

Tyre:12R22.5 tire 12+1

Kin Pin:Bolt 2.0inch or 3.5inch

Landing Gear:28Ton

Hydraulic Cylinder:Complete hydraulic cylinder with hydraulic system

Brake Chamber:Six double chambers

Lamps:A full set of LED lights

Voltage :24V

Receptacle:7 ways

Tool Box:one

Spare Wheel Carrier:One
